QuicRun WP10BL80-G2 ESC 80A 2-4s

Hobbywing QuicRun WP 10BL80 Crawler ESC

Waterproof electronic speed controller for RC models and model ship propulsion systems

The Hobbywing QuicRun WP 10BL80 Crawler is a powerful electronic speed controller (ESC) for 1/10 scale RC models that supports both brushless and brushed motors. With a continuous current capacity of 80 A and support for 2–4 S LiPo batteries, the controller offers reliable and precise power control for demanding applications.

The compact design and robust construction make the QuicRun WP 10BL80 a versatile solution for use in a wide variety of models where control, reliability and resistance to environmental influences are crucial.

Performance features of the Hobbywing QuicRun WP 10BL80

The controller impresses with its high efficiency and sensitive control of the motor across the entire speed range. The integrated high-voltage BEC with selectable output voltage allows powerful servos to be powered directly without additional electronics. Clean signal processing ensures precise throttle response and controlled handling, especially at slow speeds.

The completely waterproof and dust-protected housing allows use in demanding conditions, such as off-road, in wet or humid environments.

Areas of application in RC model making

The QuicRun WP 10BL80 Crawler ESC has been specially developed for RC crawlers, scale vehicles and off-road models in 1/10 scale. It is ideal for applications that require high load capacity, precise control and reliable electronics. Support for brushless and brushed motors offers additional flexibility in the choice of drive system.

Suitable for model ship drives

Thanks to its waterproof design, stable power supply and sensitive control, the QuicRun WP 10BL80 is also suitable for use as a speed controller in model ships. In conjunction with suitable brushless or brushed motors, the controller can be used in scale boats, functional models and work and supply ships. The controller offers reliable and consistent power output, especially in applications with longer running times and changing loads.

Advantages for model builders

The Hobbywing QuicRun WP 10BL80 Crawler ESC combines high load capacity, flexible motor support and robust design in a compact controller. It is a versatile drive component for model builders who are looking for a reliable and weatherproof ESC for RC vehicles or model ships.

Technical data Hobbywing QuicRun WP 10BL80 Crawler

Type: Electronic speed controller (ESC)
Motor support: Brushless and brushed
Continuous current: 80 A
Peak current: up to 240 A
Operating voltage: 2–4 S LiPo
BEC: High voltage BEC
BEC output voltage: 6.0 V / 7.4 V / 8.4 V
BEC output current: up to 11 A
Dimensions: approx. 36 × 30 × 15.5 mm
Weight: approx. 48 g
Protection class: waterproof and dustproof
Cooling: optional fan possible
