Razer Eight Motor 4268/150A 1600KV ESC Combo

119.00€ * 145.90€ * (18.44% Saved)

Prices incl. VAT plus shipping costs

delivery time 2-7 working days Europe longer

  • R01260
  • Robitronic
  • Neuer Artikel
Motor and regulator Combi Razoreight Razereight motor 4268 with 1600KV The Razereight is a... more
Product information "Razer Eight Motor 4268/150A 1600KV ESC Combo"

Motor and regulator Combi Razoreight

Razereight motor 4268 with 1600KV

The Razereight is a sensorless high performance motor designed for maximum power. High torque and perfect power delivery make this motor the first choice for your model.

Features:
-4-pole rotor design for high torque and fast response.
CNC-milled, high-strength aluminium housing for optimum heat dissipation
-Motor winding made of pure, double-insulated copper wire
-Precision ball bearings for best running smoothness and durability
-Highly flexible silicone connection cables with pre-soldered 4mm plugs
-High strength and polished 5mm steel rotor shaft

Razereight 150A regulator

The Razereight 150A regulator has all the important features and adjustment options on board that an ambitious model builder desires. Due to the outstanding quality you get a controller with highest reliability and best efficiency.

All cables are already wired ready for connection, no soldering necessary.
Battery connection: T-connector,
Motor connection: 4mm sockets

Features:
-completely waterproof and dustproof controller (does not apply to the motor).
-ON/OFF switch with setup button
-S-BEC with 6V and 5A peak current
-Plug and Play, battery and motor connector already soldered
-Multiple protections: Low voltage cut-off, thermal protection and loss of signal protection.
-Simple programming via set-up button
-Separate programming port, easy connection of LED programme card (optional).

Technical data Controller:
Constant/peak current: 150A / 950A
Type: Sensorless
Motor limit: 4s LiPo: 4274 motor, <=3000KV
6s LiPo: 4274 motor, <=2400KV
Internal resistance: 0.00035 Ohm
LiPo / NiMH battery pack: 3-6s LiPo / 8-18 cells MiMH
S-BEC: 6V/5A
Programming Port: Yes
Dimensions LxWxH: 59.5x48x42mm
Weight: 178g

Technical data motor:
Item No.: R01240
Idle speed: 1600KV
LiPo cells: 2s-6s
Poles: 4
Shaft diameter/length: 5mm/18mm
Dimensions D/L: 42mm/68mm
Weight (incl. cable) 338g
